How to programming MDBT42Q chip with NRF52-DK

RE: How to programming MDBT42Q chip with NRF52-DK

awneil — Fri, 28 May 2021 09:14:10 GMT

RE: How to programming MDBT42Q chip with NRF52-DK

erdidedemli — Fri, 28 May 2021 07:17:48 GMT

Hello everyone again, after long research and exchange of information with the employees of the distrubutor company in Turkey, I learned that the MDBT42Q-ATM module is actually programmed only with AT commands. As a result, I bought the MDBT42Q-512KV2 module that I will Program with Segger. I finally programmed it with Segger. Below, I will share the circuit diagram necessary to program this module with NRF52-DK.

VDD nRF-------------------> (MDBT42Q)V DD


VDD------------+
               |
VTG------------+

SWD IO ----------------->(MDBT42Q) SWD IO


SWD CLK ---------------->(MDBT42Q) SWD CLK

GND DETECT------------+
                      |
GND-------------------+

GND------------------->(MDBT42Q) GND

RE: How to programming MDBT42Q chip with NRF52-DK

awneil — Tue, 04 May 2021 09:46:57 GMT

So have you been to the Raycom website, and found the page with all the supporting information for that product? And the Raycom Support contact details?

RE: How to programming MDBT42Q chip with NRF52-DK

erdidedemli — Tue, 04 May 2021 07:39:32 GMT

Raytac manufacturer MDBT42Q module

RE: How to programming MDBT42Q chip with NRF52-DK

awneil — Tue, 04 May 2021 07:37:24 GMT

[quote userid="103186" url="~/f/nordic-q-a/74679/how-to-programming-mdbt42q-chip-with-nrf52-dk/308063#308063"]where can I get manufacturer's documentation[/quote]

How can you intend to use any chip if you don't have the manufacturer's documentation for it?

You haven't even said who the manufacturer is yet.

https://www.avrfreaks.net/comment/2839426#comment-2839426

https://www.avrfreaks.net/comment/2842546#comment-2842546

they are for a different manufacturer but, as noted, pretty much all manufacturers have basically the same idea ...

RE: How to programming MDBT42Q chip with NRF52-DK

erdidedemli — Tue, 04 May 2021 07:00:02 GMT

Hello, I'm a little new to this field . where can I get manufacturer's documentation ?

RE: How to programming MDBT42Q chip with NRF52-DK

awneil — Mon, 03 May 2021 09:02:08 GMT

If this "MDBT42Q" exposes the SWD interface, of course you can.

Again, what does the manufacturer's documentation tell you?

RE: How to programming MDBT42Q chip with NRF52-DK

erdidedemli — Mon, 03 May 2021 08:59:55 GMT

can I use Segger for programming ?

RE: How to programming MDBT42Q chip with NRF52-DK

awneil — Mon, 03 May 2021 08:06:26 GMT

The MDBT42Q documentation should tell you how to program it - either via a bootloader, or using the SWD. If that's unclear, you need to contact the manufacturer for support.

The nRF52-DK can program external SWD targets - instructions are in the User Guide:

https://infocenter.nordicsemi.com/topic/ug_nrf52832_dk/UG/nrf52_DK/hw_debug_out.html
