Why the output amplitude decreases when C decrease?

[kygomax]

Hello,

I was trying to build Clapp oscillator with a JFET J310 (FYI:link text)as it is shown in the figure.

Capacitor C is variable and goes from 20 pF to 285 pF. I have connected C3 in series to get suitable equivalent capacitance. With the given values I should get frequencies between 800 kHz and 2 MHz. The simulation confirms this.

However, the circuit on the bench does not behaves as in the simulation. With C = 285 pF I get about 800 kHz with about 3.6 Vpp. Once I start to decrease C the output amplitude starts to decrease and at about 1.5 MHz the oscillator stops. Shouldn't the amplitude be approximately constant as it is in the simulation? Why it decreases? Does the transistor gain goes down and why?

（I have tried with a breadboard and with a PCB (Manhattan style) and the results are the same.）

[RK]

What has this got to do with Nordic ?

[Håkon Alseth]

I would recommend posting this on stackoverflow or similar forums that has a generic electronics section: electronics.stackexchange.com/

I will not try to answer your question directly, but in general when it comes to simulations vs. reality; there's always something that will differ. Why? It can be many things, like component variances/tolerances, variances in production, temperature, and other factors. Since this is fairly low frequency, I do not think long wires has a huge impact, but in general; keep your lines short and simple. Good luck and have a nice weekend!
