what is the maximum limit for PWM outputs pins on nrf52832? Can we use all the GPIO pins as a PWM output?

[akshaey]

Hello

what is the maximum limit for PWM outputs pins on nrf52832? Can we use all the GPIO pins as a PWM output?

For ADC, i can see there are 8 dedicated pins , but i want to confirm for PWM that if there are any GPIO pins which can't be used as PWM o/p.

Thanks for your time

[Sigurd]

Hi,

Yes, any available GPIO pin can be used as PWM. The nRF52832 has 12 hardware PWM channels with DMA, and also allows 8 GPIOTE based PWM channels. So you have 20 PWM channels in total.

[omar]

Hi, There are specific GPIO pins for hardware and software PWM channels ? What are the pin numbers for hardware PWM channels please ? (nRF52832 QFN48)

[Sigurd]

Hi omar,

You can use any free GPIO you want. Note that if you are using the nRF52832-DK, some of the pins are used for e.g. LEDs and buttons. See this drawing. If you are looking for a simple hardware PWM example, take a look at this post.

[omar]

Thank you Sigurd for your help !

[kyj17096]

But in section  "4.3 GPIO usage restrictions" in "nRF52832 Product Specification v1.4",  it  recommend pin27, pin 28 .. pin43 of QFN48 package only used to Low drive, low frequency I/O, so it seems that some pins are not suitable for pwm, is it right?
