UICR / FICR in linux

[Jean-Louis Bonnaffé]

Hello Community,

Does anyone know how to read/write configuration registers (UICR, FICR) on nRF51822 in a linux environment ?

So far, I have to stick with Windows for these operations (nrfjprog, nRFgo Studio).

[Eirik Midttun]

The way to do it is to download JLink and run it from the command line. I have described how to program and erase the nRF51 chip in this blog post. I have not tried manipulating the UICR or FICR, but it should be a normal register write. See the nRF51 reference manual to find the memory addresses.

[Clem Taylor]

I have never used nrfjprog or nrfgo studio, I do everything in gdb.

I build the UICR data into a hex file and then just manually load it in gdb.

With the rev2 silicon I never managed to get the NVMC_ERASEUICR to work, so I just do a eraseall prior to program UICR.

From my gdb.jlink config file:

set $NVMC_READY              = ((uint32_t*)0x4001E400)
set $NVMC_CONFIG             = ((uint32_t*)0x4001E504)
set $NVMC_ERASEALL           = ((uint32_t*)0x4001E50C)
set $UICR_BOOTLOADERADDR     = ((uint32_t*)0x10001014)

define wait-nvmc-ready
   if *$NVMC_READY != 1
       printf "Wait for NVMC_READY\n"
       while *$NVMC_READY != 1
           shell sleep 0.1
       end
   end
end

define erase-all
   mon halt

   wait-nvmc-ready
   printf "Erasing entire flash...\n"
   # 0=REN, 1=WEN, 2=EEN
   set *$NVMC_CONFIG    = 2

   # 1=start chip erase
   set *$NVMC_ERASEALL  = 1
   wait-nvmc-ready
   mon sleep 500

   # 0=REN, 1=WEN, 2=EEN
   set *$NVMC_CONFIG    = 0

   mon reset

   printf "Done...\n"
end

define program-uicr
   mon halt

   printf "UICR.BOOTLOADERADRR = 0x%08X\n", *$UICR_BOOTLOADERADDR

   printf "Compile bin/xxx.UICR.hex\n"
   make bin/xxx.UICR.hex

   printf "Loading bin/xxx.UICR.hex\n"
   wait-nvmc-ready

   # 1=WEN
   set *$NVMC_CONFIG    = 1

   load bin/xxx.UICR.hex
   wait-nvmc-ready
   mon sleep 500

   # 0=REN
   set *$NVMC_CONFIG    = 0

   # verify
   printf "UICR.BOOTLOADERADRR    = 0x%08X\n", *$UICR_BOOTLOADERADDR
   printf "xxxInfoUICR.magic = 0x%08X\n", xxxInfoUICR.magic
   printf "xxxKeysUICR.magic = 0x%08X\n", xxxKeysUICR.magic
   printf "xxxKeysUICR.crc   = 0x%08X\n", xxxKeysUICR.crc
end

[Jean-Louis Bonnaffé]

Nice post. It works with the magic register writes and exit sequence, as follows : J-Link>w4 4001e504 2 J-Link>w4 4001e50c 1 J-Link>w4 10001014 00038000 J-Link>r J-Link>g
