nrf52832 uart tx works only with NRF_UARTE0 read after EndTx

[FormerMember]

Greetings, There is a bit of strange operation in UARTE peripheral in nrf52832 with the DK. In the simple code below, if both of the if statements with comments 'Check 1' and 'Check 2' are removed the 'hello' prints are not sent and I get some junk value. If either of the two reads to the UARTE registers is made in these if statement, then the 'hello' prints are sent out correctly. What's happening? I don't see any errata related to UARTE peripheral.

Thanks.

Toolchain: GCC 4.9.3q2 on Linux

#include <stdbool.h>
#include <stdint.h>
#include "nrf_delay.h"
#include "nrf52-gpio.h"
#include "nrf52-clock.h"
#include "board.h"
#include "nrf52-uart.h"

int main(void)
{
	nrf_gpio_cfg_output(LED1);
	nrf_gpio_cfg_output(LED2);
	nrf_gpio_cfg_output(LED3);
	nrf_gpio_cfg_output(LED4);

	/* Configure TX and RX pins from board.h */
	nrf_gpio_cfg_output(TX_PIN_NUMBER);
	nrf_gpio_cfg_input(RX_PIN_NUMBER, GPIO_PIN_CNF_PULL_Disabled);
	NRF_UARTE0->PSEL.TXD = TX_PIN_NUMBER;
	NRF_UARTE0->PSEL.RTS = RX_PIN_NUMBER;

	nrf_gpio_cfg_output(RTS_PIN_NUMBER);
	nrf_gpio_cfg_input(CTS_PIN_NUMBER, GPIO_PIN_CNF_PULL_Disabled);
	NRF_UARTE0->PSEL.RTS = RTS_PIN_NUMBER;
	NRF_UARTE0->PSEL.CTS = CTS_PIN_NUMBER;
	NRF_UARTE0->CONFIG = (UARTE_CONFIG_HWFC_Enabled << UARTE_CONFIG_HWFC_Pos);

	/* Configure other UART parameters, BAUD rate is defined in nrf52-uart.h	*/
	NRF_UARTE0->BAUDRATE = (UARTE_BAUDRATE << UARTE_BAUDRATE_BAUDRATE_Pos);
	NRF_UARTE0->ENABLE = (UARTE_ENABLE_ENABLE_Enabled << UARTE_ENABLE_ENABLE_Pos);

    // Toggle LEDs.
    while (true)
    {
    	uint32_t i;
        for (i = 0; i < 2; i++)
        {
        	if(i){
        		NRF_P0->OUTSET = (1<<LED1);
        	} else {
        		NRF_P0->OUTCLR = (1<<LED1);
        	}
        	nrf_delay_ms(500);

            uint8_t str[] = "hello\n";
            uint32_t len = 6;

            NRF_UARTE0->EVENTS_ENDTX = 0;
            NRF_UARTE0->TASKS_STOPTX = 0;

        	NRF_UARTE0->TXD.PTR = (uint32_t)((uint8_t *) str);
        	NRF_UARTE0->TXD.MAXCNT = (uint32_t) len;

        	NRF_UARTE0->TASKS_STARTTX = 1;

        	while((0 == NRF_UARTE0->EVENTS_ENDTX)&&(0 == NRF_UARTE0->EVENTS_TXSTOPPED)){}

            /*****Check 1*****/
        	if(NRF_UARTE0->EVENTS_ENDTX){
        		NRF_P0->OUTSET = (1<<LED3);
        	}

            /*****Check 2*****/
        	if(6 == NRF_UARTE0->TXD.AMOUNT){
        		NRF_P0->OUTSET = (1<<LED2);
        	}

            NRF_UARTE0->EVENTS_ENDTX = 0;
            NRF_UARTE0->TASKS_STOPTX = 0;
        }
    }
}

[Susheel Nuguru]

Something is fishy, works in Keil if I remove If statement at check 1, but does not work in GCC. This seems to be something related to compiler rather than the hardware. Not sure though. Later today I will compare assembly instruction of KEIL and GCC output.

[FormerMember]

I'm using Og optimization as of now, if that helps. Is this something like what is described in the 'Interrupt clearing' section of 'Migrating from nrf51 to nrf52'? Thanks for the help.

[Susheel Nuguru]

I had to see into this all day and still did not get any valid software explanation yet. Tomorrow maybe i should start looking into it as a hardware issue.

[Susheel Nuguru]

im still investigating this, this seems to be much trickier than previously anticipated. GCC behavior is very strange with optimizations enabled. Before pointing my finger to GCC bug, i will have to make sure what exactly it did at different optimizations. Need more time.

[Susheel Nuguru]

Finally, I am answering assuming that you are working on windows. This is GCC bug, if you are using 4_9-2015q2-20150609 There is some issue with it when you enable optimizations.

NRF_UARTE0->TASKS_STOPTX = 0;

You cannot do this, or more specifically it will have no effect.

files to analyse main.asm.dump main.no_asm.dump
