I have found multiple PDFs indicating the lay-out on the nRF52-DK. However, none of them tell me anything about the size of the kit. Does anyone have a PCB lay-out with at least the width and height of the PCB?
I have found multiple PDFs indicating the lay-out on the nRF52-DK. However, none of them tell me anything about the size of the kit. Does anyone have a PCB lay-out with at least the width and height of the PCB?
The hardware files are available for download as gerbers here. That gives you the exact dimensions and layouts.
That's a big folder with a lot of files. Can you narrow it down which one I need?
You need a gerber viewer or Altium designer to get the exact dimensions. Dimensions are not available in the PDF files.
@Christopher I have both, but as said, the link is a whole bunch of files. I'm simply looking for dimensions, not for megabytes of information.
You do not need the production files if you have Altium.
Unzip and open the 400150.PcbDoc
Altium file available in the nRF52-DK - Hardware files 0_9_0/PCA10040-nRF52832 Bluetooth Smart,ANT,2.4GHz RF Development Board 0_9_0/Altium Designer files/
folder.
