Mian code -
/*
* Codec-style I2S SLAVE playback using k_mem_slab
* nRF54Lx DK
*/
#include <zephyr/kernel.h>
#include <zephyr/device.h>
#include <zephyr/devicetree.h>
#include <zephyr/drivers/i2s.h>
#include <zephyr/sys/printk.h>
#include "codec/codec.h"
#define I2S_NODE DT_NODELABEL(i2s20)
//audio
#define SAMPLE_RATE_HZ 8000
#define SAMPLE_BIT_WIDTH 32
#define CHANNELS 2
#define SAMPLES_PER_BLOCK 160
//#define SAMPLES_PER_BLOCK (SAMPLE_RATE_HZ / 10) // 33ms blocks
#define BLOCK_SIZE (SAMPLES_PER_BLOCK * CHANNELS * sizeof(int16_t))
#define NUM_BLOCKS 80
#define TIMEOUT_MS 2000
static const struct device *i2s_dev = DEVICE_DT_GET(I2S_NODE);
// memory slab for I2S TX buffers
K_MEM_SLAB_DEFINE(i2s_tx_slab, BLOCK_SIZE, NUM_BLOCKS, 4);
//sine
// static int16_t sine_lut[] = {
// 3211, 6392, 9511, 12539, 15446, 18204, 20787, 23169,
// 25329, 27244, 28897, 30272, 31356, 32137, 32609, 32767,
// -3212, -6393, -9512, -12540, -15447, -18205, -20788, -23170,
// -25330, -27245, -28898, -30273, -31357, -32138, -32610, -32767};
static int16_t sine_lut[] = {
6392, 12539, 18204, 23169, 27244, 30272, 32137, 32767, 32137,
30272, 27244, 23169, 18204, 12539, 6392, 0, -6393, -12540,
-18205, -23170, -27245, -30273, -32138, -32767, -32138, -30273, -27245,
-23170, -18205, -12540, -6393, -1};
// static int16_t sine_lut[8] = {
// 0,
// 23170,
// 32767,
// 23170,
// 0,
// -23170,
// -32768,
// -23170
// };
// Fill block
static void fill_block(int16_t *buf)
{
int lut_len = ARRAY_SIZE(sine_lut);
for (int i = 0; i < SAMPLES_PER_BLOCK; i++)
{
int16_t s = sine_lut[i % lut_len];
buf[2 * i] = 25000;
buf[2 * i + 1] = 25000;
}
}
int main(void)
{
struct i2s_config cfg;
int ret;
printk("I2S playback (mem_slab)\n");
// clocking and codec init
ret = pwm_4mhz();
if (ret < 0)
{
printk("PWM init failed\n");
return ret;
}
for (int i = 0; i < 20; i++)
{
ret = i2c_init_codec();
if (ret == 0)
{
break;
}
k_msleep(5);
}
if (ret < 0)
{
printk("Codec init failed\n");
return ret;
}
k_msleep(10);
// printk("BLOCK=%d SAMPLES=%d\n", BLOCK_SIZE, SAMPLES_PER_BLOCK);
if (!device_is_ready(i2s_dev))
{
printk("I2S not ready\n");
return -ENODEV;
}
// I2S CONFIG
cfg.word_size = SAMPLE_BIT_WIDTH;
cfg.channels = CHANNELS;
cfg.format =I2S_FMT_DATA_FORMAT_I2S;; //cfg.format = I2S_FMT_DATA_FORMAT_LEFT_JUSTIFIED;
cfg.options = I2S_OPT_FRAME_CLK_SLAVE |
I2S_OPT_BIT_CLK_SLAVE;
cfg.frame_clk_freq = SAMPLE_RATE_HZ;
cfg.block_size = BLOCK_SIZE;
cfg.timeout = TIMEOUT_MS;
cfg.mem_slab = &i2s_tx_slab;
ret = i2s_configure(i2s_dev, I2S_DIR_TX, &cfg);
if (ret < 0)
{
printk("I2S config failed\n");
return ret;
}
printk("Start streaming\n");
//prefill
for (int i = 0; i < 30; i++)
{
void *block;
k_mem_slab_alloc(&i2s_tx_slab, &block, K_FOREVER);
fill_block((int16_t *)block);
i2s_buf_write(i2s_dev, block, BLOCK_SIZE);
}
ret = i2s_trigger(i2s_dev, I2S_DIR_TX, I2S_TRIGGER_START);
if (ret < 0)
{
printk("I2S trigger failed\n");
return ret;
}
while (1)
{
void *block;
ret = k_mem_slab_alloc(&i2s_tx_slab, &block, K_FOREVER);
if (ret < 0)
{
printk("Slab alloc failed\n");
k_sleep(K_USEC(30));
continue;
}
fill_block((int16_t *)block);
ret = i2s_buf_write(i2s_dev, block, BLOCK_SIZE);
// k_sleep(K_USEC(100));
if (ret == -ENOMEM)
{
/* Queue full — try again */
k_mem_slab_free(&i2s_tx_slab, block);
printk("free=%d\n", k_mem_slab_num_free_get(&i2s_tx_slab));
continue;
}
else if (ret < 0)
{
printk("I2S error %d\n", ret);
i2s_trigger(i2s_dev, I2S_DIR_TX, I2S_TRIGGER_DROP);
k_sleep(K_MSEC(5));
// i2s_trigger(i2s_dev, I2S_DIR_TX, I2S_TRIGGER_PREPARE);
// k_sleep(K_MSEC(2));
i2s_trigger(i2s_dev, I2S_DIR_TX, I2S_TRIGGER_START);
k_mem_slab_free(&i2s_tx_slab, block);
printk("free=%d\n", k_mem_slab_num_free_get(&i2s_tx_slab));
continue;
}
}
i2s_trigger(i2s_dev, I2S_DIR_TX, I2S_TRIGGER_DROP);
printk("Exit\n");
return 0;
}
Log:
SEGGER J-Link V9.10 - Real time terminal output SEGGER J-Link EDU V11.0, SN=261002460 Process: JLink.exe *** Booting nRF Connect SDK v3.2.1-d8887f6f32df *** *** Using Zephyr OS v4.2.99-ec78104f1569 *** I2S playback (mem_slab) PWM configured: period=250ns pulse=125ns I2C bus ready, addr=0x18 Codec responded: reg0 = 0x01 Writing codec register table... reg=0x01 val=0x01 err=0 reg=0x04 val=0x03 err=0 reg=0x05 val=0xD4 err=0 reg=0x06 val=0x20 err=0 reg=0x07 val=0x00 err=0 reg=0x08 val=0x00 err=0 reg=0x1B val=0x0C err=0 reg=0x0B val=0x84 err=0 reg=0x0C val=0x99 err=0 reg=0x0E val=0x80 err=0 reg=0x1D val=0x01 err=0 reg=0x1E val=0x84 err=0 reg=0x3F val=0xD4 err=0 reg=0x40 val=0x00 err=0 reg=0x41 val=0x00 err=0 reg=0x42 val=0xD0 err=0 reg=0x47 val=0x82 err=0 reg=0x48 val=0x82 err=0 reg=0x51 val=0x80 err=0 reg=0x52 val=0x00 err=0 reg=0x53 val=0x00 err=0 reg=0x1E val=0x00 err=0 reg=0x1F val=0xC0 err=0 reg=0x20 val=0xC6 err=0 reg=0x23 val=0xA8 err=0 reg=0x24 val=0x80 err=0 reg=0x25 val=0x80 err=0 reg=0x22 val=0x30 err=0 reg=0x2A val=0x3D err=0 reg=0x2B val=0x3D err=0 reg=0x2C val=0xC0 err=0 reg=0x26 val=0x80 err=0 reg=0x27 val=0x80 err=0 reg=0x2E val=0x00 err=0 reg=0x2F val=0x00 err=0 reg=0x30 val=0x00 err=0 reg=0x31 val=0x00 err=0 Codec init DONE. I2C ready Start streaming [00:26:31.169,121] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200070d8 [00:26:31.169,370] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200075d8 [00:26:31.169,611] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20007ad8 [00:26:31.169,852] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20007fd8 [00:26:31.170,093] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200084d8 [00:26:31.170,332] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200089d8 [00:26:31.170,573] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20008ed8 [00:26:31.170,815] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200093d8 [00:26:31.171,052] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200098d8 [00:26:31.171,288] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20009dd8 [00:26:31.171,525] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000a2d8 [00:26:31.171,762] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000a7d8 [00:26:31.172,000] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000acd8 [00:26:31.172,234] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000b1d8 [00:26:31.172,471] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000b6d8 [00:26:31.172,708] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000bbd8 [00:26:31.172,946] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000c0d8 [00:26:31.173,183] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000c5d8 [00:26:31.178,428] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000cad8 [00:26:31.178,670] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000cfd8 [00:26:31.178,910] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000d4d8 [00:26:31.179,147] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000d9d8 [00:26:31.179,384] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000ded8 [00:26:31.179,621] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000e3d8 [00:26:31.179,859] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000e8d8 [00:26:31.180,096] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000edd8 [00:26:31.180,332] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000f2d8 [00:26:31.180,569] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000f7d8 [00:26:31.180,807] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000fcd8 [00:26:31.181,044] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200101d8 [00:26:31.181,313] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200106d8 [00:26:31.181,565] <dbg> i2s_nrf[00:26:31.181,719] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200075d8/(nil) x: i2s_nrfx_write: Queued TX 0x20010bd8 [00:26:31.182,083] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200110d8 [00:26:31.182,318] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200115d8 [00:26:31.191,702] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200070d8 [00:26:31.191,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20007ad8/(nil) [00:26:31.192,189] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20011ad8 [00:26:31.201,702] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200075d8 [00:26:31.201,943] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20007fd8/(nil) [00:26:31.202,189] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20011d58 [00:26:31.211,702] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20007ad8 [00:26:31.211,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200084d8/(nil) [00:26:31.212,189] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20011fd8 [00:26:31.221,702] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20007fd8 [00:26:31.221,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200089d8/(nil) [00:26:31.222,190] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20012258 [00:26:31.231,702] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200084d8 [00:26:31.231,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20008ed8/(nil) [00:26:31.232,190] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200124d8 [00:26:31.241,702] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200089d8 [00:26:31.241,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200093d8/(nil) [00:26:31.242,189] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20012758 [00:26:31.251,702] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20008ed8 [00:26:31.251,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200098d8/(nil) [00:26:31.252,190] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200129d8 [00:26:31.261,703] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200093d8 [00:26:31.261,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20009dd8/(nil) [00:26:31.262,190] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20012c58 [00:26:31.271,703] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200098d8 [00:26:31.271,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000a2d8/(nil) [00:26:31.272,190] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20012ed8 [00:26:31.281,703] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20009dd8 [00:26:31.281,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000a7d8/(nil) [00:26:31.282,190] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20013158 [00:26:31.291,704] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000a2d8 [00:26:31.291,945] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000acd8/(nil) [00:26:31.292,191] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200133d8 [00:26:31.301,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000a7d8 [00:26:31.301,939] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000b1d8/(nil) [00:26:31.302,195] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000a7d8 [00:26:31.311,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000acd8 [00:26:31.311,939] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000b6d8/(nil) [00:26:31.321,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000b1d8 [00:26:31.321,939] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000bbd8/(nil) [00:26:31.322,195] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000b1d8 [00:26:31.331,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000b6d8 [00:26:31.331,939] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000c0d8/(nil) [00:26:31.341,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000bbd8 [00:26:31.341,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000c5d8/(nil) [00:26:31.342,194] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000bbd8 [00:26:31.351,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000c0d8 [00:26:31.351,939] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000cad8/(nil) [00:26:31.361,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000c5d8 [00:26:31.361,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000cfd8/(nil) [00:26:31.362,196] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000c5d8 [00:26:31.371,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000cad8 [00:26:31.371,939] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000d4d8/(nil) [00:26:31.381,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000cfd8 [00:26:31.381,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000d9d8/(nil) [00:26:31.382,196] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000cfd8 [00:26:31.391,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000d4d8 [00:26:31.391,938] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000ded8/(nil) [00:26:31.401,719] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000d9d8 [00:26:31.401,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000e3d8/(nil) [00:26:31.402,200] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000d9d8 [00:26:31.411,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000ded8 [00:26:31.411,939] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000e8d8/(nil) [00:26:31.421,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000e3d8 [00:26:31.421,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000edd8/(nil) [00:26:31.422,196] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000e3d8 [00:26:31.431,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000e8d8 [00:26:31.431,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000f2d8/(nil) [00:26:31.441,715] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000edd8 [00:26:31.441,938] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000f7d8/(nil) [00:26:31.442,191] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000edd8 [00:26:31.451,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000f2d8 [00:26:31.451,939] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000fcd8/(nil) [00:26:31.461,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000f7d8 [00:26:31.461,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200101d8/(nil) [00:26:31.462,197] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000f7d8 [00:26:31.471,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000fcd8 [00:26:31.471,939] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200106d8/(nil) [00:26:31.481,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200101d8 [00:26:31.481,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20010bd8/(nil) [00:26:31.482,196] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200101d8 [00:26:31.491,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200106d8 [00:26:31.491,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200110d8/(nil) [00:26:31.501,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20010bd8 [00:26:31.501,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200115d8/(nil) [00:26:31.502,197] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20010bd8 [00:26:31.511,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200110d8 [00:26:31.511,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20011ad8/(nil) [00:26:31.521,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200115d8 [00:26:31.521,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20011d58/(nil) [00:26:31.522,197] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x200115d8 [00:26:31.531,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20011ad8 [00:26:31.531,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20011fd8/(nil) [00:26:31.541,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20011d58 [00:26:31.541,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20012258/(nil) [00:26:31.542,197] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20011d58 [00:26:31.551,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20011fd8 [00:26:31.551,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200124d8/(nil) [00:26:31.561,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20012258 [00:26:31.561,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20012758/(nil) [00:26:31.562,196] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20012258 [00:26:31.571,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200124d8 [00:26:31.571,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200129d8/(nil) [00:26:31.581,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20012758 [00:26:31.581,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20012c58/(nil) [00:26:31.582,193] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20012758 [00:26:31.591,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200129d8 [00:26:31.591,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20012ed8/(nil) [00:26:31.601,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20012c58 [00:26:31.601,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20013158/(nil) [00:26:31.602,197] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20012c58 [00:26:31.611,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20012ed8 [00:26:31.611,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200133d8/(nil) [00:26:31.621,721] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20013158 [00:26:31.621,945] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000a7d8/(nil) [00:26:31.622,201] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20013158 [00:26:31.631,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200133d8 [00:26:31.631,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000b1d8/(nil) [00:26:31.641,716] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000a7d8 [00:26:31.641,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000bbd8/(nil) [00:26:31.642,197] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000a7d8 [00:26:31.651,719] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000b1d8 [00:26:31.651,943] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000c5d8/(nil) [00:26:31.661,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000bbd8 [00:26:31.661,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000cfd8/(nil) [00:26:31.662,197] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000bbd8 [00:26:31.671,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000c5d8 [00:26:31.671,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000d9d8/(nil) [00:26:31.681,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000cfd8 [00:26:31.681,943] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000e3d8/(nil) [00:26:31.682,199] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000cfd8 [00:26:31.691,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000d9d8 [00:26:31.691,940] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000edd8/(nil) [00:26:31.701,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000e3d8 [00:26:31.701,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000f7d8/(nil) [00:26:31.702,197] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000e3d8 [00:26:31.711,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000edd8 [00:26:31.711,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200101d8/(nil) [00:26:31.721,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000f7d8 [00:26:31.721,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20010bd8/(nil) [00:26:31.722,196] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000f7d8 [00:26:31.731,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200101d8 [00:26:31.731,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x200115d8/(nil) [00:26:31.741,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20010bd8 [00:26:31.741,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20011d58/(nil) [00:26:31.742,198] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20010bd8 [00:26:31.751,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x200115d8 [00:26:31.751,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20012258/(nil) [00:26:31.761,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20011d58 [00:26:31.761,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20012758/(nil) [00:26:31.762,198] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20011d58 [00:26:31.771,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20012258 [00:26:31.771,938] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20012c58/(nil) [00:26:31.781,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20012758 [00:26:31.781,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20013158/(nil) [00:26:31.782,198] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20012758 [00:26:31.791,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20012c58 [00:26:31.791,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000a7d8/(nil) [00:26:31.801,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20013158 [00:26:31.801,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000bbd8/(nil) [00:26:31.802,198] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20013158 [00:26:31.811,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000a7d8 [00:26:31.811,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000cfd8/(nil) [00:26:31.821,717] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000bbd8 [00:26:31.821,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000e3d8/(nil) [00:26:31.822,198] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000bbd8 [00:26:31.831,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000cfd8 [00:26:31.831,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000f7d8/(nil) [00:26:31.841,722] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000e3d8 [00:26:31.841,946] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20010bd8/(nil) [00:26:31.842,203] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000e3d8 [00:26:31.851,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000f7d8 [00:26:31.851,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20011d58/(nil) [00:26:31.861,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20010bd8 [00:26:31.861,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20012758/(nil) [00:26:31.862,198] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20010bd8 [00:26:31.871,720] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20011d58 [00:26:31.871,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20013158/(nil) [00:26:31.881,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20012758 [00:26:31.881,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000bbd8/(nil) [00:26:31.882,198] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20012758 [00:26:31.891,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20013158 [00:26:31.891,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000e3d8/(nil) [00:26:31.901,720] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000bbd8 [00:26:31.901,944] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20010bd8/(nil) [00:26:31.902,200] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000bbd8 [00:26:31.911,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000e3d8 [00:26:31.911,941] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20012758/(nil) [00:26:31.921,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20010bd8 [00:26:31.921,943] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000bbd8/(nil) [00:26:31.922,199] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x20010bd8 [00:26:31.931,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20012758 [00:26:31.931,942] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x20010bd8/(nil) [00:26:31.941,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000bbd8 [00:26:31.941,958] <dbg> i2s_nrfx: i2s_nrfx_write: Queued TX 0x2000bbd8 [00:26:31.942,173] <dbg> i2s_nrfx: i2s_nrfx_write: Next TX 0x2000bbd8 [00:26:31.942,382] <dbg> i2s_nrfx: supply_next_buffers: Next buffers: 0x2000bbd8/(nil) [00:26:31.951,718] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x20010bd8 [00:26:31.961,705] <err> i2s_nrfx: Next buffers not supplied on time [00:26:31.961,931] <dbg> i2s_nrfx: free_tx_buffer: Freed TX 0x2000bbd8 [00:26:31.962,177] <err> i2s_nrfx: Cannot write in state: 4 I2S error -5 ASSERTION FAIL [p_cb->state != NRFX_DRV_STATE_UNINITIALIZED] @ WEST_TOPDIR/modules/hal/nordic/nrfx/drivers/src/nrfx_i2s.c:439 [00:26:31.962,647] <err> os: r0/a1: 0x00000004 r1/a2: 0x000001b7 r2/a3: 0x00000000 [00:26:31.962,889] <err> os: r3/a4: 0x00000004 r12/ip: 0x0000000a r14/lr: 0x00007f01 [00:26:31.963,123] <err> os: xpsr: 0x09000000 [00:26:31.963,303] <err> os: Faulting instruction address (r15/pc): 0x0000e364 [00:26:31.963,524] <err> os: >>> ZEPHYR FATAL ERROR 4: Kernel panic on CPU 0 [00:26:31.963,743] <err> os: Current thread: 0x20000a28 (main) [00:26:31.963,947] <err> os: Halting system
no sine wave sound during this trasmission time ?..
I attached here reguster i Enabaled
/**
* Register declaration
*/
const register_value REGISTER_DATA[] = {
// # reg[0][0] = 0x00 ; Select Page 0
{0,0x00}, // Select Page 0
/* Software reset */
{1,0x01},
/* ---------- PLL CONFIG (MCLK = 4 MHz → 8 kHz Fs) ---------- */
{4,0x03}, // PLL input = MCLK, CODEC_CLK = PLL
{5,0xD4}, // PLL power up, P=5, R=4 D4
{6,0x20}, // J=32
{7,0x00}, // D MSB
{8,0x00}, // D LSB
// *** PLL LOCK WAIT (VERY IMPORTANT) ***
/* ---------- I2S DIGITAL ---------- */
{27,0x0C}, // I2S, 16bit, slave 0C
/* ---------- DAC CLOCK TREE ---------- */
{11,0x84}, // NDAC=4, power up
{12,0x99}, // MDAC=25, power up
{14,0x80}, // DOSR=128 → Fs = 8kHz
{29,0x01}, // DAC clock source 0x01
{30,0x84}, // BCLK divider 84
/* ---------- DAC POWER / UNMUTE ---------- */
{63,0xD4}, // Soft stepping D4
{64,0x00}, // Left DAC unmute
{65,0x00}, // Right DAC unmute
{66,0xD0}, // DAC volume 00 dB
{71,0x82}, // beep
{72,0x82},
{81,0x80},
{82,0x00},
{83,0x00},
/* ===================================================== */
/* ===================== PAGE 1 ========================= */
/* ===================================================== */
{0,0x01}, // Select Page 1
/* ---------- Analog Power ---------- */
{30,0x00}, // Analog blocks power control
{31,0xC0}, // HPL + HPR unmute
{32,0xC6}, // Speaker drivers power up
/* ---------- DAC → Headphone ---------- */
{35,0xA8}, // Route DAC L/R → HP
{36,0x80}, // HP volume 0 dB
{37,0x80}, // HP volume 0 dB
/* ---------- Speaker ---------- */
{34,0x30}, // Speaker path enable
{42,0x3D}, // Speaker gain 1D
{43,0x3D}, // Speaker gain 1D
{44,0xC0}, // Speaker unmute
/* ---------- Route DAC → Speaker ---------- */
{38,0x80},
{39,0x80},
/* ---------- MIC (optional) ---------- */
{46,0x00}, // MICBIAS 2.5V 0x0A
{47,0x00}, // MIC gain
{48,0x00}, //0x40
{49,0x00}, //0x40
};
i m usinf nrf54l15 and codec is TLV320AIC3111
